How to control servo motor using joystickjoystick control servo motor Circuit Diagram This is a joystick-controlled motor driving system. An Arduino UNO reads inputs from an Adafruit Arcade Joystick and outputs control signals to BTS7960 motor drivers, which in turn power several 12V geared motors. The system is designed for directional control of motors, suitable for applications such as robotic vehicles or motorized platforms. This code allows you to control the speed and direction of a DC motor using the Y-axis of a joystick. The motor will stop when the joystick is in the central position, rotate forward when the joystick is pushed upward, and rotate backward when the joystick is pulled downward, with the speed proportional to the joystick's position. up/down controller, TV up/down controller are few application examples. The board provides superb performance, smooth movement of motor, and hassle-free use. You only need to connect the motor wires, power the board, and you ready to go.The controller has 3 main elements, Atmega328 Micro-Controller, LMD18201 DC Motor H-bridge, and Joystick
Additionally, the further away from the center the joystick is pushed (in either direction), the faster the motor speed will be in that same direction. So, users can control the DC motor speed in this way. The joystick control method for DC motors is currently used in several different applications, including as: 1. This post shows how to control a DC motor speed and direction of rotation using Arduino uno, joystick and L293D motor driver. The joystick (PS2 Joystick) consists of two potentiometers (one for the X-axis and the other for the Y-axis) and a push-button. With one potentiometer we can control the speed and rotation direction of a DC motor.
